Firecryl FR


Soudal Firecryle FR

Description
Firecryl FR is a one-component intumescent plastoelastic joint sealant based on acrylic dispersions.
EC1 Plus Firecryl FRCharacteristics
– Resist the passage of fire and smoke
– Fire resistant up to 4 hours with PE backer rod (EN 1366 Part 4-NBN713.020- BS 476/20)
– Intumescent in contact with fire
– Swells when exposed to temperatures in excess of 120°C
– Stays elastic and can be painted over
– Colourfast and waterproof after curing
– Very good adhesion on many porous surfaces
– Can be painted over after curing
Applications
– Interior fire-resistant applications
– Fire-resistant sealing compound for cracks in concrete and plaster
– Fire-resistant connection joints in the building industry
– Fire-resistant joints with movements up to 10%.

pdf-icon



DOP | TDS | MSDS | VOC


Soudaseal FR


Description
Soudaseal FR is a high quality single component joint sealant with high adhesive strength and excellent elasticity. It is based on MS-Polymer®,
chemically neutral and fully elastic. For use in high movement joints in construction, automotive, marine and aerospace areas where a tough flexible rubber is required with good fire retardant characteristics.
EC1 PlusSoudaseal FRCharacteristics
– High bond strength on nearly all surfaces
– Excellent adhesion on porous substrates
– High performance mechanical properties
– Flexible elastic rubber
– Straightforward application even in adverse conditions
– No bubble formation within sealant (in high temperature and humidity applications)
– Primerless adhesion on many substrates (except where water pressure may occur)
– Very easy to tool and finish
– Colour stability and UV resistant
– Ecological advantages – free of isocyanates, solvents, and acids
– Minimal health and safety considerations
– Overpaintable with all water based paints and many other systems
– Excellent weather resistance in all climates
– No staining of porous materials such as natural stone, granite (for marble please test a small area)
Applications
– Expansion and connection joints in the building industry
– Sealing of joints in prefabricated buildings
– Movement joints in high rise constructions
– Sealing between window and door frames
– Flexible joints in marine applications
– Flexible bonding in caravans and mobile structures
– Exposed movement joints on all usual building substrates

pdf-icon



DOP | TDS | MSDS  |  VOC  | ACOUSTIC TEST REPORT


Fire Silicone B1 FR


fire-silicone-b1-fr

Description
Firesilicone B1 FR is a high quality, neutral, elastic, one-component sealant based on silicones which conforms to the DIN4102 B1 standard for fire retardancy and has a fire rating of up to 4 hours in certain joint configurations (EN 1366 Part 4 – NN713.020 – BS 476/20).
Characteristics
– Very easy to apply
– Colourfast and UV-resistant
– Remains permanently elastic after full cure
– Very good adhesion on most surfaces
– Low modulus
– DIN 4102-Part 2: Class B1
– Up to 4 hours fire rating with normal PE backing material (see table enclosed)
Applications
– All building and glazing joints which require a fire rating
– Fire rated expansion joints

pdf-icon



DOP | TDS


Soudafoam FR


SOUDAFOAM FR

Description
Soudafoam FR is a single-component, selfexpanding, ready to use polyurethane foam with propellants which are completely harmless to the
ozone layer. It has a fire rating of up to 360 minutes in certain configurations.
Characteristics
– Fire retardant up to 360 min – see table enclosed
– Efficient seal against smoke and gas
– Does not contain CFC’s and H-CFC’s
– Excellent adhesion on most substrates (except Teflon, PE and PP)
– High thermal and acoustical insulation
– High bonding strength
– Very good filling characteristics
– Excellent stability: no shrink or post expansion
– Can be painted after full cure
Applications
– Fire retardant installation of window- and doorframes
– Fire- and smoke retardant sealing of connections between partition walls, ceilings and floors
– Filling of cavities
– All applications where fire retardant characteristics are required such as:
– sealing of all openings in roof constructions
– sealing of cable- and pipe penetrations
– creation of a sound-proof screen
– bonding of insulation materials
– application of sound-deadening layers
– improving thermal insulation in cold store area’s

pdf-icon



DOP | TDS | MSDS


Soudafoam FR Gun Click & Fix


duravalve
Description
Soudafoam FR Gun is a one-component, selfexpanding, ready to use polyurethane foam. It contains propellants, which are completely harmless to the ozone layer and greenhouse effect.
It has a fire rating of up to 240 minutes ( tested according EN1366-4 ).
Characteristics
– Fire retardant up to 240 minutes – see table enclosed
– Efficient seal against smoke and gas
– Excellent adhesion on most substrates (exempt Teflon, PE and PP)
– High thermal and acoustical insulation
– High bonding strength
– Very good filling characteristics
– Excellent stability: no shrink or postexpansion
– Can be painted after full cure
– Fitted with the Click&Fix system for ultimate ease in application
Applications
– Fire retardant installation of window- and doorframes
– Fire- and smoke retardant sealing of connections between partition walls, ceilings and floors
– Filling of cavities
– All applications where fire retardant characteristics are required such as:
– sealing of all openings in roof constructions
– sealing of cable- and pipe penetrations
– creation of a sound-proof screen
– bonding of insulation materials
– application of sound-deadening layers
– improving thermal insulation in cold store area’s

pdf-icon



DOP | TDS | MSDS


Soudafoam FR Gun Grade


duravalve
Description
Soudafoam Gun FR is a one-component, fire retarding, self-expanding, ready to use PU foam, which contains propellants who are not harmful for the ozone layer. Soudafoam FR is a PU foam with fire retardant characteristics according to the Aust Standard AS1530.4-2005 and European standard EN 1366-4. It is fitted with Soudal’s revolutionary new Duravalve which ensures longer shelf life, non-clogging and higher yield per can
Features & Benefits
  • Non shrink, no post expansion
  • Fire retardant up to 240 mins
  • High filling capacity
  • Good adhesion on all surfaces
  • High insulation value, thermal and acoustic
Applications
Perfect for the fast filling and insulating of cavities, openings, and gaps in all types of building materials. Fire and smoke retardant sealant between walls, floors and ceilings. Installation of fireproof doors and windows. Excellent acoustic properties

pdf-icon



  TDS


Firecement HT


firecement ht

Description
Firecement HT is a single component ready to use heat resistant sealant which cures to form a hard seal. It withstands temperatures of up to 1500°C.
Characteristics
– Heat resistant up to 1500°C
– Does not contain asbesto or other harmful components
– Hard setting
– Does not crumble or crack after cure
– Fire Rating of 120 minutes (Test Report 7830)
Applications
Sealing of joints and openings at furnaces, heating systems, central heatings, barbecues, etc. Heat retardant sealing at existing constructions

pdf-icon



TDS | MSDS


Silirub HT-A


Description
Silirub HT°-A is an elastic, single component engineering sealant based on silicone which withstands very high temperatures.
Characteristics
  • Permanent elastic after curing
  • Temperature resistance up to 285°C
  • Excellent adhesion on metals, glass and glazed substrates
  • Typical acetic smell
Applications
Sealing of heating installations. Sealing in pumps and engines. All sealing applications that require high temperature resistance

pdf-icon



TDS
